220v Single Phrase Gear Oil Transfer Pump , Electric Motor Water Ring Vaccum Pump

China 220v Single Phrase Gear Oil Transfer Pump , Electric Motor Water Ring Vaccum Pump supplier
220v Single Phrase Gear Oil Transfer Pump , Electric Motor Water Ring Vaccum Pump supplier 220v Single Phrase Gear Oil Transfer Pump , Electric Motor Water Ring Vaccum Pump supplier 220v Single Phrase Gear Oil Transfer Pump , Electric Motor Water Ring Vaccum Pump supplier 220v Single Phrase Gear Oil Transfer Pump , Electric Motor Water Ring Vaccum Pump supplier

Large Image :  220v Single Phrase Gear Oil Transfer Pump , Electric Motor Water Ring Vaccum Pump

Product Details:

Place of Origin: China
Brand Name: Yuzhou
Certification: ISO/SGS/CE
Model Number: 2BV

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: plywood case package
Delivery Time: 2-5 working days
Payment Terms: T/T, Western Union
Supply Ability: 500 sets per month
Contact Now
Detailed Product Description
Product Name: Gear Oil Transfer Pump Model: 2BV
Feature: Vaccum Pump Material: Cast Iron/stainless Steel
MOQ: 1 Set Colour: Customized
High Light:

waste oil gear pump

,

gear lube transfer pump

2BV series 380v 220v single phrase electric motor water ring vaccum pump​



2BV series vacuum pump works basing on water ring principle, that is, impeller is installed eccentrically inside of pump body, after the pump start up, working liquid forms liquid ring(which is concentric with pump body ) inside of pump body, impeller passes motor power to liquid ring. Liquid ring pulse periodically between the impeller vanes, while in pulsation, gas is suctioned in through disk suction inlet and discharged from disk exhaust vent.



  • The close-coupled design is convenient to install and can save space.
  • The bearings are all used the imported products with brand name of NTN or NSK
  • The standard seals are all used the John Crane mechanical seals, eliminating leakage, easy maintenance
  • 2BV series products have the cavitation protection port. When they work under the condition near the limited vacuum, the cavitation protect port opens (or connects with the separator)to get rid of the screaming to protect the pump.
  • Aluminum bronze impeller is of high intensity and wearing well. The erosive-proof capacity of the pump can be improved by using it. If the parts where the liquid flows are made of the stainless steel,the pumps can be used under the more rigorous condition.
  • The unique design of the discharge port can protect the pump from the over-pressure to ensure the best efficient performance in the working range of the 2BV vacuum pump.
  • The motors are all adopted Y2 series products. The protection class is IP54 or IP55 (normal is IP44) and the insulation grade is F.(normal is B).
  • 2BVwater ring vacuum pump can achieve all of the PTFE flexible seal, which can greatly extend the working life in more demanding conditions
  • Running smoothly, the noise can be as low as 62 db.



Technical parameters:





Model Pumping capacity

Ultimate

vacuum

mbar(MPa)

Motor

Power

(KW)

Explosion

-proof

class

Motor

protection

class

Speed

(r/min)

Water

consumption

(L/min)

Noise

dB(A)

Weight

(kg)

m3/min m3/h
2BV2060 0.45 27

33mbar

(-0.098MPa)

0.81 No EX IP54 2840 2 62 31
2BV2061 0.86 52 1.45 2840 2 65 35
2BV2070 1.33 80 2. 35 2860 2.5 66 56
2BV2071 1.83 110 3. 85 2880 4. 2 72 65
2BV2060-Ex 0.45 27 1.1 dIIBT4 IP55 2840 2 62 39
2BV2061-Ex 0.86 52 1.5 2840 2 65 45
2BV2070-Ex 1.33 80 3 2860 2.5 66 66
2BV2071-Ex 1.83 110 4 2880 4.2 72 77
2BV5110 2.75 165 4 No EX IP54 1440 6. 7 63 103
2BV5111 3.83 230 5.5 1440 8.3 68 117
2BV5121 4.66 280 7.5 1440 10 69 149
2BV5131 6.66 400 11 1460 15 73 205
2BV5161 8.33 500 15 970 20 74 331
2BV6110 2.75 165 4





dIIBT4









IP55





1440 6.7 63 153
2BV6111 3.83 230 5.5 1440 8.3 68 208
2BV6121 4.66 280 7.5 1440 10 69 240
2BV6131 6.66 400 11 1460 15 73 320
2BV6161 8.33 500 15 970 20 74 446

220v Single Phrase Gear Oil Transfer Pump , Electric Motor Water Ring Vaccum Pump
