220v/380v/12v Electric Mini LPG Transfer Pump YQB Series For LPG Filling Station

China 220v/380v/12v Electric Mini LPG Transfer Pump YQB Series For LPG Filling Station supplier
220v/380v/12v Electric Mini LPG Transfer Pump YQB Series For LPG Filling Station supplier 220v/380v/12v Electric Mini LPG Transfer Pump YQB Series For LPG Filling Station supplier 220v/380v/12v Electric Mini LPG Transfer Pump YQB Series For LPG Filling Station supplier 220v/380v/12v Electric Mini LPG Transfer Pump YQB Series For LPG Filling Station supplier

Large Image :  220v/380v/12v Electric Mini LPG Transfer Pump YQB Series For LPG Filling Station

Product Details:

Place of Origin: China
Brand Name: Yuzhou
Certification: ISO, SGS, CE
Model Number: YQB

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Packing in wooden cases for export
Delivery Time: 3-7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 sets/month
Contact Now
Detailed Product Description
Power: 220v/380v/50hz/60hz /single Phrase /three Phrase Flow Rate: 1m3/h~80m3/h
Color: Blue Or Customized Pressure: Pressure: 2.5 Mpa
Warranty: 1 Year Product Name: LPG Transfer Pump
High Light:

lpg petrol pump

,

lpg filling pump

YQB series Lpg transfer pump with explosion motor 220v single phrase for nigeria market



Descreption:



YQB series Lpg transfer pump with explosion motor 220v single phrase for nigeria market, mainly used for liquefied petroleum gas, propane and butane, are also suitable for filling or transporting volatile liquids and petroleum products of similar properties. The pump is a volumetric vane pump with advanced structure. The stator curved surface is composed of a composite curve. The two ends are mechanically sealed. The fixed-fit end faces are all made of “O”-type sealing ring. The rotating moving parts are made of metal corresponding non-metal. It has the function of safe and reliable use and multi-purpose use



YQB series Lpg transfer pump Advantages:



1. Innovative cam desigb virtually eliminates cavitation



2. New materials utilized in cam and blades and heavy duty bearings extend pump life



3. Single mechanical seal, very easy seal replacement and maintenance



4. Large diameter non-metallic pins are suitable for higher pump speeds



YQB series Lpg transfer pump Technical details:



Model Speed n Flow Q

Pressure difference

ΔP

Working pressure

P

Power

N

Inlet size Outlet size

Temperature

YQB1-5 600r.P.m 1 m3/h 0.5MPa 2.0MPa 1.5KW 1'' 1'' +40-40
YQB2-5 600r.P.m 2 m3/h 0.5MPa 2.0MPa 1.5KW 1'' 1'' +40-40
YQB3-5 600r.P.m 3 m3/h 0.5MPa 2.0MPa 1.5KW 1'' 1'' +40-40
YQB5-5 780r.P.m 5 m3/h 0.5Mpa 1.6Mpa 2.2KW 1'' 1'' +40-40
YQB10-5 780r.P.m 10m3/h 0.5MPa 1.6MPa 5.5KW 2'' 2'' +40-40
YQB15-5 780r.P.m 15m3/h 0.5Mpa 1.6Mpa 5.5kw 2'' 2'' +40-40
YQB25-5 600r.P.m 25m3/h 0.5MPa 1.6MPa 11KW 3'' 3'' +40-40
YQB35-5 780r.P.m 35m3/h 0.5Mpa 1.6Mpa 11kw 3'' 3'' +40-40
YQB50-5 600r.P.m 50 m3/h 0.5MPa 1.6MPa 15KW 4'' 4'' +40-40
YQB60-5 780r.P.m 60 m3/h 0.5MPa 1.6MPa 15KW 4'' 4'' +40-40
YQB80-5 780r.P.m 80 m3/h 0.5MPa 1.6MPa 18.5KW 4'' 4'' +40-40



Notes:



When the pump is use, it is strictly forbidden to pump out and reverse. If the pump outlet does not discharge, stop the pump immediately, check the cylinder at the inlet for liquid, prevent the pump from pumping out, and damage the pump. (Weighing cylinders use electrons as the best, and digital changes can tell if there is no liquid). If there is a possibility of failure and troubleshooting in the cylinder.



1 No pressure, no fluid.

(1) Check the steering,

(2) Check the pipeline switch, the cylinder valve, the inlet filter is not blocked (3) Check the inverted cylinder for liquid.

2 Vibration and voice.

(1) Check if the outlet valve is open,

(2) Bearing damage, change the bearing.
